Fitment
1991-1996 Toyota Camry
1992-1996 Lexus ES300
Installation Instructions
Always replace both lift supports to ensure top performance and to prevent twisting caused by uneven loading.
1. Turn off ignition. If old lift support has a window demister electrical connection, carefully disconnect the fittings.
2. Before removing old lift supports, examine any fittings supplied to determine which components must be re-used.
3. Have someone hold the hatch, bonnet, boot or rear window open while replacing the lift supports.
4. Loosen the fasteners, remove one end while being prepared to fight the pressure in the strut, move the end so
it's away from the bodywork, remove the other end, install that end of the new one, wrestle the other end
into place and tighten up.
5. Make sure all connectors and hardware are in place, tight and secure. Reconnect electrical terminals at both
ends of the gas-charged lift support, if applicable to your car. Retain plastic end caps, if applicable to your car.
WARNING
Use safety stands whenever a procedure requires you to be under the vehicle.
Features & Advantages
* Our Lift support have the industry's highest quality in terms of long-lasting performance, smooth operation,
functional safety, and ease of installation.
* Our Liftsupport have 2 Year's Warranty. * We feature the latest technology and most innovative features. Each
gas charged lift support is tested in four different positions during compression and extension to measure speed
and force. Each lift is then subjected to two overload tests to assure structural integrity and safety.
* Enhances performance through improved oil and gas Pressure sealing.
* Manufactured with bearing quality precision to promote longer operating life.
